Product Description
CG 501C is a premium carbon graphite packing optimized for centrifugal and rotary pump sealing applications. Engineered to deliver superior performance with minimal product contamination for sensitive processes.
Quick Specifications
Temperature Range
-200°C to +650°C (2750°C in Non Oxidizing media)
pH Range
0-14
Size Range
3 mm² to 25 mm² cross-section
Technical Data
Specifications
| Equipment Type | Pressure | Velocity |
|---|---|---|
| Rotating | 150 bar | 25 m/s |
| Reciprocating | 300 bar | 20 m/s |
| Static | 350 bar | --- |
Common Specifications
Temperature Range-200°C to +650°C (2750°C in Non Oxidizing media)
pH Range0-14
Size Range3 mm² to 25 mm² cross-section
Additional Technical Data
CertificationISO 15848-1
Benefits
Key Features
High-performance premium-grade carbon graphite for pump sealing
Excellent resilience and recovery properties maintain sealing effectiveness
Superior wear resistance in abrasive service environments
Easy installation with minimal break-in period required
Minimal product contamination characteristics for clean services
Clean service suitable for sensitive industrial processes
Good thermal conductivity and lubrication properties
Universal chemical resistance across diverse media
Low particulate generation for clean applications
Use Cases
Applications
Centrifugal pumps
Process pumps
Reciprocating pumps
Industrial valves
Refinery equipment
Petrochemical processing systems
Power generation facilities
Chemical processing plants
General industrial sealing applications
Anti-extrusion ring applications
Additional Support?
Contact our sales team for pricing, availability, and technical specifications.
